Air conditioning service unit, quadruple certified, 9 kg

Entry-level quadruple certified A/C service unit. Automatic refrigerant recycling, UV and oil management. Convenient software update via USB port. Thanks to a new modular concept, basic ASC can be turned to a service unit for either R134a, R1234yf, R456A or R513A refrigerants, depending on the appropriate connection kit, for one refrigerant type of your choice (sold separately).
art.nr : 9103303104
Safe and secure
Safe and secure

Electronic fan control

Unique in this class
Unique in this class

Used oil drainage bottle on weighing cell

Unique in this class
Unique in this class

Fresh oil and UV bottle on weighing cell

...And more
    • Entry-level A/C service unit – competitive price
    • Humidity-free storage and feeding system for fresh oil and UV additive supplied with the associated connection kit (sold separately)
    • Automatic refrigerant recycling, UV and oil management controlled by load cell
    • USB interface for convenient software update or export of service data
    • Purity of the recovered refrigerant complies with the SAE J 2099 standard
    • Minimum 95 % refrigerant recycling rate
    • Soft graphic display – can also display special characters

The perfect entry-level A/C service unit

The low investment ASC 6100 G is ideal for anyone who has just started to provide A/C service on R134a, R1234yf, R456A or R513A air conditioners. Offering you all the features required to work safely, it also saves you time by performing all service processes automatically. The purity of the recovered refrigerant complies with the SAE J 2099 standard. Expecting more orders in the future? You can easily upgrade your service unit at a later date – add a heat belt for the charging cylinder, or our humidity-free storage and feeding system for fresh oil and UV additive. A USB port for convenient software updates and soft graphic display which can display special characters are already included.

Frequently asked questions


SKU number 9103303104
For Refrigerant R1234yf, R134a, R513A
Input voltage (AC) 220-240 V
Input frequency 50/60 Hz
Purity of recovered refrigerant (SAE J 2099) Yes
Refrigerant recovery rate 30.00 kg/h
Vacuum pump capacity 5 cars/h
Performance of the hermetic compressor 0.32 kW
Dry filter capacity 150.00 kg
Refrigerant recycling rate Min. 95 %
Can be used as diagnosis tool No
Refrigerant Capacity 11.00 kg
Refrigerant analysis No
Recovery/recycling Automatic
Purging of non-condensable gases Automatic
Purging of used oil Automatic
Evacuation Automatic
Vacuum check Automatic
Nitrogen leak check No
Injection of leak detection additive Automatic
Injection of oil into the A/C system Automatic
Refrigerant charging Automatic
High/low pressure indicated by Manometer
Vacuum indicated by Display
Total process control indicated by Display
Option to set the evacuation time Yes
Protocol print-out possible No
Dimensions product depth 600 mm
Dimensions product height 1040 mm
Dimensions product width 600 mm
Net weight 90 kg
EAN-13 4000907019385
Dimensions parcel depth 900 mm
Dimensions parcel height 1500 mm
Dimensions parcel width 800 mm
Parcel weight 100 kg
